IPPC-6172A-R1BE |
IPPC-6172A-R2AE |
| General |
BIOS |
AMI 4 MB Flash BIOS |
AMI 64 MB Flash BIOS |
| Environment |
Humidity |
5 ~ 85% @ 4C (non-condensing) |
5 ~ 95% @ 40°C (non-condensing) |
| Ingress Protection |
Front panel: IP65 |
Front panel: IP65 |
| Temperature (Operating) |
0 ~ 50° C (32 ~ 122° F) |
0 ~ 50° C (32 ~ 122° F) |
| Temperature (Storage) |
-20 ~ 60° C (-4 ~ 140° F) |
-20 ~ 60° C (-4 ~ 140° F) |
| Vibration Protection |
5 ~ 500 Hz, 1 GRMS random vibration |
5 ~ 500 Hz, 1 GRMS random vibration |
| General |
Certifications |
UL, CE, FCC, CCC, BSMI |
UL, CE, FCC, CCC, BSMI |
| Dimensions (W x H x D) |
481.9 x 355.9 x 144.7 mm (18.97" x 14.01" x 5.7") |
481.93 x 355.87 x 132.5 mm (18.97" x 14.01" x 5.22") |
| Enclosure |
Die-cast flat-sealed front with SGCC Housing |
Die-cast flat-sealed front with SGCC Housing |
| Mounting |
Panel, Rack (option) |
Panel, Rack (option) |
| OS Support |
Windows 7, Windows XP |
Microsoft Windows 7, Windows 8 |
| Power Input |
100 ~ 240 VAC @ 60 ~ 50 Hz, 7 ~ 3.5 A |
100 ~ 240 VAC @ 60 ~ 50 Hz, 7 ~ 3.5 A |
| Power Supply |
350 W |
350 W |
| LCD Display |
Backlight Life |
50,000 hrs |
50,000 hrs |
| Contrast Ratio |
1000:01:00 |
1000:01:00 |
| Display Size |
17" |
17" |
| Display Type |
SXGA TFT LCD LED Backlight |
SXGA TFT LCD LED Backlight |
| Luminance (cd/m2) |
350 |
350 |
| Max. Colors |
16.7M (RGB 6-bit + Hi-FRC data) |
16.7M (RGB 6-bit + Hi-FRC data) |
| Max. Resolution |
1280x1024 |
1280x1024 |
| Viewing Angle (H/V°) |
170/160 |
170/160 |
| System Hardware |
Chipset |
Intel Q45 GMCH/ICH10D0 |
Intel Q87 |
| CPU |
Supports Socket LGA775 based up to Intel Core 2 Quad 2.8 GHz/Core 2 Duo 3.0 GHz |
Supports Intel® Core™ i7/i5/i3 processor (up to 3.1GHz ) |
| Expansion |
Two half-length PCI (Standard) Two PCIe x1(Optional) One PCI + One PCIe x4 (Optional) |
Two half-length PCI (Standard) Two PCIe x1(Optional) One PCI + One PCIe x4 (Optional) |
| I/Os |
2 x RS-232, 1 x RS-232/422/485, 5 x USB 2.0 (one at front), 2 x PS2 (Keyboard, Mouse), 1 x VGA Port, Mic-in, Line-in, Line-out |
4 (3 x RS-232, 1 x RS-232/422/485 to support auto flow control), 1 x GPIO, 2 x Reservation ports, 5 x USB Host( USB 2.0 front, 4 USB 3.0) 2 x GbE LAN |
| LAN |
10/100/1000Base-T Ethernet x 2 |
10/100/1000Base-T Ethernet x 2 |
| Memory |
Two DDR3 240pin slots up to 4GB 1066/1333 MHz SDRAM |
System supports four DIMM sockets support up to 32GB DDR3 1333/1600 MHz SDRAM |
| Optical Driver |
1 x Slim Type DVD-RW |
1 x Slim Type DVD-RW (optional), CFast (optional) |
| Storage |
Supports 2 x 2.5" SATA HDD Interface and Intel Matrix Storage Technology RAID 0/1 |
Supports 2 x 2.5" SATA HDD Interface and Intel Matrix Storage Technology RAID 0/1 |
| Touchscreen |
Lifespan |
36 million with a silicone rubber of R8 finger, writing rate is by 250g at 2 times/s |
36 million with a silicone rubber of R8 finger, writing rate is by 250g at 2 times/s |
| Light Transmission |
> 80% |
> 80% |
| Touch Type |
Analog Resistive 5 wires |
Analog Resistive 5 wires |
